3D modeling cost is driven by five independent variables , none of which is simply "how big is the building." Two facilities of identical square footage can differ by a factor of five or more in modeling cost depending on geometry complexity, the number of systems being modeled, and the specified Level of Development. Understanding these variables is the key to writing an accurate scope and receiving a meaningful scope-defined proposal.
GDS Project Support
Most physical-to-digital projects touch more than one discipline. Depending on the scope, GDS can support the workflow from field capture through usable engineering deliverables with 3D Laser Scanning, 3D Modeling, reverse engineering, and Consulting.
GDS lists office locations in Torrance, California and Houston, Texas, and posted service coverage across major metros including Houston, Dallas, San Antonio, Austin, Los Angeles, San Diego, San Jose, Long Beach, Fort Worth, Irvine, Riverside, New Orleans, Baton Rouge, Shreveport, Las Vegas, and Beverly Hills. Confirm the current posted coverage on the GDS locations page.
Scope note: Accuracy, tolerance, deliverable format, registration method, pricing structure, schedule, access conditions, safety requirements, and any certification or compliance needs should be defined in the quote, proposal, or statement of work. This article is educational and should not be treated as a project guarantee.
Modeling Cost Is Separate from Scanning Cost
In a full Scan-to-BIM program, the total project investment has two distinct components: field scanning (capturing the point cloud) and post-processing modeling (building the BIM model from the cloud). These are independently scoped and priced. For a large industrial facility at LOD 300, modeling typically accounts for measurable of total project cost , the majority of the investment is in the skilled engineering time to build the model, not in the field work.
Clients requesting only point cloud delivery pay only for scanning and registration. Clients requesting a fully developed BIM model pay for scanning plus modeling , two separate, additive scopes.
The Five Modeling Cost Variables
1. Level of Development (LOD)
LOD is the single most impactful modeling cost driver. Each LOD tier requires substantially more engineering time per element modeled:
| LOD | Elements Modeled | Modeling Hours per Element (Typical) | Relative Cost |
|---|---|---|---|
| LOD 200 | Generic shapes, approximate location | Low | Baseline |
| LOD 300 | Precise geometry, accurate dimensions | Moderate | 2 to 4× LOD 200 |
| LOD 350 | Precise geometry with connections | High | 4 to 7× LOD 200 |
| LOD 400 | Fabrication-level detail | Very high | 8 to 12× LOD 200 |
Specifying LOD 350 when the project only requires coordination clash detection (LOD 300) adds substantial cost with no engineering benefit.
2. Geometry Complexity
Simple, regular geometry (rectangular rooms, straight pipe runs, orthogonal structural steel) models faster than complex geometry (curved ducting, non-orthogonal structures, custom-fabricated equipment). A single custom pump skid with non-standard connections and irregular mounting geometry may take as long to model as 50 linear metres of standard structural steel.
Key complexity indicators that increase modeling cost:
- Non-orthogonal structures (sloped roofs, curved walls)
- Dense overhead piping with numerous fittings, valves, and branch connections
- Custom or non-standard equipment with unique envelope geometry
- Aging infrastructure with heavy corrosion and deformation that must be interpreted through scan noise
3. Number of Systems to Be Modeled
Each discipline system (structural, architectural, civil, mechanical equipment, process piping, fire protection, HVAC, electrical cable trays, instrumentation) is modeled independently and adds a proportional cost increment. Modeling all systems at LOD 300 costs four to six times more than modeling structural and piping alone.
GDS recommends defining the minimum set of systems required for the project's specific downstream use:
- Tie-in design for a new unit: process piping + structural + equipment only
- Full renovation coordination: all MEP disciplines
- Insurance documentation: structural + architectural + major equipment
4. BIM Family and Content Creation
When the facility contains equipment or components not available in standard BIM content libraries, the GDS project team must create parametric BIM families from the scan data. Custom family creation , for specialized industrial equipment, custom fabricated vessels, or legacy process machinery , is billed per family and can add significant cost on facilities with extensive non-standard equipment inventories.
Clients who can provide equipment datasheets and OEM cut sheets reduce family creation time and cost.
5. Deliverable Platform and Format
Different deliverable platforms carry different modeling tool licensing and deliverable preparation overhead:
| Platform | Notes |
|---|---|
| Autodesk Revit (.rvt) | Industry standard for AEC; highest ecosystem compatibility |
| AutoCAD 3D (.dwg) | Simpler deliverable; lower modeling overhead |
| Bentley MicroStation (.dgn) | Common in heavy civil and infrastructure |
| IFC (open BIM) | Additional export and validation step; no additional modeling |
| Navisworks (.nwd) | Coordination model assembled from source models |
Indicative Modeling Cost Ranges
Note: Ranges are indicative only. A meaningful proposal requires defined LOD, system scope, platform, and deliverable requirements.
| Scope | Indicative Modeling Cost (USD) |
|---|---|
| LOD 200 , single discipline, < 1,000 m² | $3,000 to $8,000 |
| LOD 300 , 2 to 3 disciplines, < 1,000 m² | $8,000 to $20,000 |
| LOD 300 , all disciplines, 1,000 to 5,000 m² | $25,000 to $80,000 |
| LOD 350 , all disciplines, 1,000 to 5,000 m² | $50,000 to $150,000 |
| LOD 350 , large industrial facility, all disciplines | $100,000 to $300,000+ |
How GDS Structures Modeling Proposals
A GDS modeling proposal should clearly define the project-specific modeling scope, such as:
- System scope: Explicit list of every discipline included and excluded
- LOD specification: Defined per system (structural at LOD 300; piping at LOD 350, etc.)
- BIM family list: Identified standard vs. custom-creation families with unit costs
- Deliverable format: Platform, file format, coordinate system, and unit specification
- Exclusions: Clearly documented items outside scope to prevent misunderstanding
Quick Facts
Continue Reading
The next best article depends on where you are in the project. These suggested reads connect this topic to the next practical decision your team is likely to face.
FAQ
Is 3D modeling included in the scanning quote?
Not automatically. GDS scopes scanning (point cloud capture and registration) and modeling (BIM or CAD reconstruction) as separate, additive project components. A scanning-only quote covers field work and point cloud delivery. A Scan-to-BIM quote includes both components. Be explicit about which deliverable you require when requesting a proposal.
What LOD should I specify for a renovation project?
LOD 300 is appropriate for most brownfield renovation coordination and tie-in design work. LOD 350 is required when fabrication-level connection details, support attachment points, and discipline interfaces must be modeled. Specifying a higher LOD than the downstream use case requires can substantially increase modeling cost without adding practical engineering value.
How do I reduce the cost of a 3D modeling project?
The three most effective cost-reduction strategies are: (1) limit LOD to the minimum required for the downstream use case; (2) restrict the system scope to only the disciplines needed for the project's engineering purpose; (3) provide OEM equipment documentation and cut sheets to reduce custom BIM family creation time.
